WHITE
(RAL 9016)
STOCK CODE
APOLLO
COLOURS
HEIGHT WIDTH WATT BTU
255 1000 4 462 1576 350.00 BALL2H1000 472.50
255 1200 4 554 1890 400.00 BALL2H1200 540.00
255 1400 4 647 2208 450.00 BALL2H1400 607.50
255 1600 4 739 2521 500.00 BALL2H1600 675.00
255 1800 4 832 2839 550.00 BALL2H1800 742.50
DIMENSIONS – LOW LEVEL
SIZE IS ACTUAL
BACK WALL TO FRONT OF RAD 140MM MIN
BACK WALL TO PIPE CENTRES 75MM MIN.
DISTANCE BETWEEN TAPPINGS WIDTH OF RAD LESS 73MM
FLOOR TO TAPPINGS CENTRE 82MM
BASSANO INFORMATION
EN442 OUTPUTS ΔT50C
CORRECTION FACTOR TO ΔT60C = 1.2675
EXAMPLE RAL STOCK CODE RAL7024_BALL2H1000
SEE ANTHRACITE STOCK RANGE ALSO 3-10 days delivery Steel Made in Belgium 5 Year Guaranty
